| The auto chain welding machine technical | |||||||
| Model | DLW-2-G30/40 | DLW-2-G30/50 | DLW-2-G30/75 | DLW-2-G30/100 | DLW-2-G30/125 | DLW-2-G30/150 | DLW-2-G30/200 |
| Diameter | 2-4.5mm | 3-6mm | 5-8mm | 6-10mm | 8-13mm | 10-16mm | 12-18mm |
| Pitch | 4-8times*Dia | 3-8times*Dia | 3-8times*Dia | 3-8times*Dia | 3-8times*Dia | 3-8times*Dia | 3-8times*Dia |
| Efficiency | 45-60ring/min | 42-56ring/min | 38-50ring/min | 33-45ring/min | 28-38ring/min | ||
| Transformer | 40KVA | 75KVA | 100KVA | 125KVA | 150KVA | 200KVA | 300KVA |
| Rated duty cycle | 50% | 50% | 50% | 50% | 50% | 50% | 50% |
| Secondary no-load voltage | 5V | 5.94V | 7.04V | 7.3V | 8.64V | ||
| Cooling type | water | water | water | water | water | water | water |
| Water Press | 0.15-0.3Mpa | 0.15-0.3Mpa | 0.15-0.3Mpa | 0.15-0.3Mpa | 0.15-0.3Mpa | 0.15-0.3Mpa | 0.15-0.3Mpa |
| Motor power | 1.1KW | 1.5KW | 2.2KW | 3KW | 4KW | 5.5KW | 7.5KW |
| Motor class | 4 | 4 | 4 | 4 | 4 | 6 | 6 |
| Size (LxWxH） | 1145x810x1560mm | 1380x920x1740mm | 1500x1000x1780mm | 1600x1100x1780mm | 1650x1160x1780mm | 1960x1250x1850mm | 2060x1360x2050mm |
| Weight（T） | 0.7T | 1.2T | 1.5T | 1.8T | 2.1T | 3.2T | 4.5T |
G80 WELDING MACHINE
G30 welding machine
